| สถานที่กำเนิด: | จีน |
| ชื่อแบรนด์: | XZH Test |
| ได้รับการรับรอง: | CE/ISO |
| หมายเลขรุ่น: | XHHV535-2L |
This device is an integrated unit that incorporates a DC high - voltage source, energy storage capacitor, discharge ball gap and so on. It effectively replaces the traditional test transformer, operating box and pulse energy storage capacitor, which used to weigh hundreds of kilograms.
★ With automatic protection functions for overcurrent, overvoltage and overheating;
★ High voltage pulse output is uniform and controllable;
★Super short-circuit protection function, which can make the high-voltage output directly short-circuit to ground;
★ It has dual 2.5-level pointer display for current and voltage, which is intuitive and clear, and the impact discharge process is clear at a glance;
★ High-voltage side voltage measurement, real-time and accurate;
★ It has zero start protection and potentiometer zero return output function, safe and reliable;
★ Unique high-voltage measurement design, in the stopped state, the voltmeter can indicate the capacitor voltage in real time;
★ The discharge time can be set arbitrarily within the appropriate interval;
Technical Parameters
| Impact voltage | 0~35kV |
| High voltage partial pressure | Level 2.5 |
| Built-in capacitor | 2μF |
| Output voltage polarity | negative polarity |
| Impact power | 400W |
| Overcurrent protection | 10A (more than 3 seconds) |
| Power | 1225J |
| Over-temperature protection | 65ºC |
| Volume | 540L×300W×450H |
| Weight | no more than 25kg |
| Working power supply | AC 220V±10%/50Hz±2Hz |
| Ambient temperature | -20~+60ºC |
